Project Description
Sinotruk HOWO A7 6×4 Dump Truck (ZZ3257M3847N1/T1WA)
China National Heavy Duty Truck HOWO A7 forward-moving 30-40 tons RHD 6X4 construction dump truck
This product has reliable structure and large loading capacity, which can load 30-40 tons.
This product has reliable structure, strong loading capacity, can load 30-40 tons, strong power, from 266hp to 420hp, reliable performance, and wide application.
The product has reliable structure, strong loading capacity, can load 30-40 tons, strong power, from 266hp to 420hp, reliable performance, and a wide range of applications.
This model can meet the requirements of construction sites and mining areas and other harsh environments.
It can meet your needs of transporting mining rocks and earth for a short distance as well as engineering construction.
It can meet your short-distance transportation of mining rocks and earth as well as engineering construction.
HOWO-A7 cab is a European style jointly developed by China National Heavy Duty Truck and Italian Giorgetto Giugiaro Design Company. Its appearance is atmospheric and bold, with smooth lines, and the painting process is of the same quality as the top car, shaping a noble and beautiful beautiful style; the large windshield brings a broader view, the rearview mirror is beautiful, with practical functions of electric and electric heating, convenient and quick; the electric lifting system reduces labor intensity and facilitates maintenance. The body and doors of the cab, in addition to adhering to the provisions of the HOWO7 series and Sweden, also refer to the results of improvements in recent years, the steering wheel of Swedish trucks, with the addition of new high-tech devices, so that in the event of a collision, the deformation of the steering column for energy absorption, so that the safety performance of HOWOA7 heavy trucks to reach world-class level; the internal configuration of the cab also reflects the design concept of comfort and humanization The interior configuration of the cab also reflects the design concept of comfort and humanization.
Specifications
| Chassis Model | ZZ3257N3647N1,ZZ3257N3847N1,ZZ3257N4147N1,ZZ3257N4347N1,ZZ3257N4647N1,ZZ3257N4947N1 |
| Driving Type | 6X4 |
| Cabin | A7-W, with one sleeper and two seats, double arm windscreen wiper system with three speeds, damped adjustable driver’s seat, with heating and ventilating system, exterior sun visor, safety belts, adjustable steering wheel, air horn, air conditioner, with transverse stabilizer, with four piont support floating suspension+shock absorber. |
| Engine | Make: SINOTRUK Diesel 4-stroke direct injection diesel engine Engine model: D12.42, 420 HP ;WD615.87,290HP,WD615.69,336HP,WD615.47,371HP Emission :Euro 2 6-cylinder in-line with water cooling, turbo-charging and intercooling Displacement: 11.596 L |
| Transmission | HW19710, 10F & 2R, with PTO |
| Steering | ZF power steering, modol ZF8118, hydraulic steering with power assistance |
| Front Axle | HF9,1×9000 KGS Steering with doubleT-cross section beam |
| Rear Axle | AC16/HC16, 2×16000 KGS Pressed axle housing, central single reduction with hub reduction, with differential locks between wheels and axles. Ratio:5.73 |
| Propeller Shaft | Double universal joint propeller shaft with gear-shaped coupling flange |
| Chassis | Frame: Uprofile parallel ladder frame with a section of 300x80x8mm, reinforced subframe all cold riveted cross members Front suspension:10 semi-elliptic leaf spring, hydraulic telescopic double-action shock absorbers, and stabilizer Rear suspension:12 leaf semi-elliptic springs, bogie spring, and stabilizer |
| Brake | Service brake: dual circuit compressed air brake Parking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheels Auxiliary brake: engine exhaust brake |
| Electrics | Operating voltage: 24 V, negative grounded Starter: 24 V, 5.4 Kw Alternator: 3-phase, 28 V, 1500 W Batteries: 2 x 12 V, 165 Ah Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light |
| Tyres | 12.00R20, radial tyres with one spare tyre |
| Fuel Tank | 300L |
| Cargo Body | Length:5.6M,5.8M,6.3M,6.8M,7.6M;Width:2.3M;Height:1.2-2M |
| Overall Dimension | 8650*2550*3450mm |
